Szczegóły Produktu
Place of Origin: China
Nazwa handlowa: Friendship Machinery
Orzecznictwo: CE, ISO
Model Number: QC11Y
Warunki płatności i wysyłki
Minimum Order Quantity: 1
Packaging Details: Standard export packing
Delivery Time: 30 working days
Supply Ability: 10 sets per month
Modelu: |
WX67Y |
Typ kontroli: |
NC |
Metoda napędzana: |
Hydrauliczne |
Modelu: |
WX67Y |
Typ kontroli: |
NC |
Metoda napędzana: |
Hydrauliczne |
1. Technical parameters
| Model | Units | WC67Y-200T/3200 | |
| Controller | / | E21 | |
| The bended steel sheet strength | N/mm2 | 450 | |
| Nominal pressure | kN | 2000 | |
| Worktable length | mm | 3200 | |
| The distance between uprights | mm | 2520 | |
| Throat depth | mm | 400 | |
| Ram stroke | mm | 200 | |
| Max opening height between worktable and ram | mm | 480 | |
| Gear pump | Model | / | CP1-40-P-10R |
| Flow | L/min | 40 | |
| Pressure | Mpa | 31.5 | |
| Ram speed | Unloaded | mm/s | 60 |
| Work | mm/s | 8 | |
| Return | mm/s | 70 | |
| Working Pressure of hydraulic system | Mpa | 26 | |
| Main motor Power | kW | 15 | |
| Electrical system | V/Hz | 3 phase,380/50 | |
| Net Weight | kg | 11500 | |
| Overall dimension | mm | 3100x1800x2850 | |
